Electricity Monitoring Software & Meter (option):
supplied with all SunPower™ products for monitoring & analysing real
time energy Savings.
Operational Principles
The inefficiency of an AC induction motors worsens when the workload
of a motor is less than full. When the actual work load of the motor
is lower than the rated load, the sensing circuit reduce the energy
being fed to the motor to the exact ampare level the motor needs. This
has the effect of reducing motor consumption.
SunPower™ Motor Saver controls the AC induction
motor so it always functions at its optimum efficiency. The Motor Saver
reduces excessive energy waste in three-phase AC induction motors. The
controller unit is providing a reduced ampares loss, reduced energy
consumption and improved power factor.
The unit monitors the phase lag of the current and voltage
relationship in a motor that is operating at less than full mechanical
load. The SunPower™ Motor Saver controller cuts back
the ampares to precisely what the motor requires to maintain the same
rated speed and torque under the present load.
Reduces Electric power consumption 10% to 48%.
Applications for the Motor Saver Applicable with 3 Phase AC Induction Motor
Product Name:
SunPower™ Motor Saver
Product
Electricity Saving Device
Category
General Industrial Equipment
Energy Monitoring System
Attributes
AC Voltage: 200, 380, 440
Volts (3 Phase)
Horsepower: 7.5 - 840 hp
KW: Maximum 630 KW
Hertz: 50 / 60 Hz
Environmental Considerations:
Ambient
temperature operating range: -10°C to 40°C. 85% non-condensing humidity
Phase / Line: 3Phase 3 Line, 3Phase 4
Line
Wiring: Series connection w/ bypass
system
Mounting: Units may be wall mounted or
put in cabinet
Through its SunPower™ Motor Saver, Conservelec is
helping companies save electricity on equipment and appliances driven by
three-phase AC induction motors, thus strengthening competitiveness.
Motor Saver reduces energy waste in AC induction motors and makes the
motor function at its optimal efficiency in proportion to load rate.
Motor Saver monitors the phase lag of the current and voltage
relationship in a motor that is operating at less than full mechanical
load. Motor Saver cuts back the voltage to precisely what the motor
requires maintaining the rated speed and torque under the present load,
thus reducing power consumption.
By reducing power consumption, SunPower™ Motor Saver reduces the need of constructing pollution-generating,
resource-consuming power plants and contributes to making clean world.
Motor Saver is an auxiliary equipment designed to control input
voltage of motor while not disturbing the production rate. Continuous
dynamic control is applied to the motor by a microprocessor which calls
Thyristor. Thyristor phase control is used to adjust the motor terminal
voltage in respond to changes of motor loading. Plug N Save uses micro
controller 8 bit at 20 MHz as CPU (central processing unit) to respond
the load change within 1/100 second.
Motor Saver working in 2 continuous action:
Limit the input current and torque to control accelertion and
deceleration of motor, referring to soft start & soft stop.
Automatically adjust voltage supplied to the motor in correspond
to the load changes, this may call Dynamic Optimization to the highest
speed of motor.
Product Specifications
Parameter
Description
Supply Voltage
110 - 380V + 10%/ -15%
Supply Frequency
47/63 Hz
Ambient Temperature
-10°C to 60°C
Storage Temperature
-40°C to 60°C
Relative Humidity
<95% - no condensation allowed
Altitude
Maximum 1000 metres. Reduce kW rating by 1% per
additional 100 metres
Starting Duty
2.5 X unit rating in amperes for 60 seconds
3 X unit rating in amperes for 30 seconds
4 X unit rating in amperes for 10 seconds
5. X unit rating in amperes for 5 seconds
Status per Hour
12 evenly spaced starts per hour at the 'Starting Duty'
ratings
Pedestal Voltage
30% to 70% of supply voltage
Starting Torque
9% to 49% of the DOL starting torque
Ramp Up Time
0.5 to 120 seconds
Ramp Down Time
0.5 to 120 seconds
Current Time
30% DOL current for 60 seconds
40% DOL current for 30 seconds
50% DOL current for 10 seconds
70% DOL current for 5 seconds
Fault Detection
Shut down for loss of phase and short-circuit Thyristor
Semiconductor Fuses
Standard on units >132 amp
Cooling
Naturally cooled <39 amps
Force cooled >53 amp
LED Indications
Power on, Run, Ramp up, Ramp down, Fault and
Optimising/Top of ramp
Relays
Run, Fault/Top of ramp
Relay Contract Rating
1.2KVA, 250V AC Max
Control Voltage
220V AC where necessary
Fan Voltage
220V as specified
Enclosure
IP20
